210cc 4 stroke Petrol High Pressure Washer
AFTER SALES SUPPORT
(toll free) MODEL No.: SHW196 • 06/2019 9885
e-mail: info.aldi@positecgroup.com
AUS
27
1300 889 028
AUS
Connecting with a garden hose (see fig. M1-M2):
1) Connect the garden hose to the water inlet of the pump (24). Pull
the garden hose to check if it is securely locked.
2) Insert the hose reel inlet (22) to the water outlet of pump (23), and
tighten it by hand in a clockwise direction.
3) Connect the 10m pressure hose (6) to the spray gun (19). Details see
Attach the 10m pressure hose (6) to the spray gun (19).
NOTE:If the water inlet of pump fitting (24) is to be replaced, the water
inlet filter on the opposite side also requires replacement. DAMAGE
will occur to the pump if the filter is not used.
M2
M1
24
1
2
