(1.3) Setup
Items not listed in (
1.1) Box Contents are sold separately.
(1.3.1) Connection Diagram
Power
Speakers*
Smartphone, MP3 player, etc.*
Computer*
Use the cable snake to connect the drum module to the
drum/cymbal pads of your electronic drum kit.
* sold separately
Music
Device*
Optional expansion tom and
cymbals available separately.
CYM 2USBPOWER TOM 4 R L/MONO AUX IN
TRIGGER INPUT AUDIO OUTPUT
0.5A9V
