Cable overview : 1 - W403
Location
Mounting
Title
Emmie w. heater
Revised date
06 5
=9014734+CP01&Circuit/10
Next page
Page
2015-03-26
Cable no Source (from)
Cable overview
Conductors
used
Target (to)
Conductors /
Area
Function textCable type
Other equivalent and approved cables may be used.
All signal cables should be a Signal Shielded Cable with the shield properly connected to earth as shown in the electrical drawings.
For power cables, armour must be connected to the earth bar.
Providing the armour is connected to the earth as shown in the electrical drawings gives sufficient EMC protection.
Note:
1) Cable not included in Alfa Laval delivery
2) Cable type and size according to VFD/motor specification
3) Optional
4) If external transformer, main supply is connected to transformer panel
Note
Ethernet to OP11 581803 45=9014734+CP01-OP1=9014734+CP01-A1
Power Supply: 1x230V 50/60Hz (Max fuse 10A) Option: 1x100/110/120V 50/60Hz (Max fuse 10A)3W001 576705 01=CUSTOMER+PS-MAINS=9014734+CP01-X1 3G1,5
Separator4W002 9009089 81=9014734+Field-M1=9014734+CP01-U1 4G1,5
Pump4W003 9005079 80=9014734+Field-M2=9014734+CP01-U2 4G1,5
Heater3W101 ÖLFLEX® CLASSIC 110 CH=9014734+Field-R1=9014734+CP01-X1 3G1,5
Tank full5W201 571937 01=9014734+Field-LS1=9014734+CP01-X2 5x0,75
Cover open2W202 554151 01=9014734+Field-S1=9014734+CP01-X2 1x2x0,75
Oil Overheat2W203 ÖLFLEX® CLASSIC 110 CH=9014734+Field-R1=9014734+CP01-X2 1x2x0,75
Pressure transmitter4W401 901747603=9014734+Field-PT1-1=9014734+CP01-X401 4x0,34
Pressure regulating valve4W402 901747604=9014734+Field-V1-1=9014734+CP01-X401 4x0,34
Temperature before separator4W403 901747603=9014734+Field-TT1=9014734+CP01-X4 4x0,34
To Next Page
