SETUTBL
Created by
SETUTBL
Revised by
Approved date
2015-10-23
Approved by
SETUNLNCAT
Department
2014-04-02
Created date Project
A2 - Analog outputs
Location
Mounting
=9014734
+CP01
Title
Emmie w. heater
Page Revision
Latest Revision
07
06
Next page
Page
30
Revised date
9014734
Document No.
2015-03-26
Pump
VFD speed
Chanel 1 Chanel 2Chanel 3 Chanel 4
X1
11
AO+01I
AnalogOutput01
X1
14
AO+03I
AnalogOutput03
X1
12
AO+01U
AnalogOutput01
+Field-V1-1:4
X1
13
AO-01
AnalogOutput01
+Field-V1-1:3
X1
16
AO-03
AnalogOutput03
X1
15
AO+03U
AnalogOutput03
-A2
X20AO4622 X20 analog output module, 4 inputs, ±10 V or 0 to 20 mA/4 to 20 mA, 12-bit resolution, configurable input filter
V2.91
X1
21
AO+02I
AnalogOutput02
-U2:3
X1
23
AO-02
AnalogOutput02
-U2:1
X1
22
AO+02U
AnalogOutput02
X1
24
AO+04I
AnalogOutput04
X1
26
AO-04
AnalogOutput04
X1
25
AO+04U
AnalogOutput04
Pressure
regulating valve
+Field
0V
2
0-10V
4
-V1-1
24V
1
0V
3
-X4
404
403
SH
SH
4x0,34
901747604
-W402
1BN 2WH 3BU4BK SH
A2.23
/23.223
A2.21
/23.224
24V-6
/ 21.207
F41.11
/ 21.205
