Installation
Lifting
Straps should b e used when lifting the hea t exchanger. Place straps acco rding to picture with a
minimum angle of 45 ° .
Warning!
Never lift by the connections or the studs around them.
Figure 4. Lifting TS6
Raising
This instructi on is valid when raising the he at exchanger after delivery from Alfa Laval. Only use
a strap approved for the weight o f the heat exchange r. Follow the pr inciple of the instructi on
below.
Caution!
The straps s hall be long enough to be able to rotate the heat exchanger without
obstruction. Consi der especially the space for the support column.
Step 1
Place two timber beams on the floor.
Document ID La nguage Edition
3490010217 EN 2016-06 Instruction Ma nual - Plate Heat Exchan gers 13
EN
