Description
Name plate
The type of unit, manufacturing number and manufacturing y ear can be found on the name
pl ate. Pressure vessel details in accordance with the applicable pr essure vessel code are also
gi ven. The name plate is fixed to the frame plate, most commonly, or the pressur e plate. The
name plate can be a steel plate or a sticker label.
Warning!
The design pressures and tempera tures for each unit are marked on the name plate.
These must not be exceeded.
Caution!
Avoid aggressive chemicals for cleaning the heat exchanger when a sticker label is used.
The design pressure (11) and the design tem perature (10), as given on the name plate, are the
values agai nst which the heat exchanger is a pproved according to the pressure vessel code in
question. The design temp erature (10) may exceed the maximum operating temperatur e (8) for
which the gaskets have been sele cted for. If the operating temperat ures as spe cified on the
PHE dr awing are to be changed the supp lier should be consulted.
1. Space for lo gotype
2. Open space
3. Website for servi ce
4. Drawing of possible locations of conne ctions/Location of 3A tag for 3A units
5. Space for mark of approval
6. Warning, read manual
7. Date of pres sure test
8. Maximum operating t emperature
9. Manufacturer test pressure (PT)
10. Al lowable temperatures Min/Max (TS)
11. Allowable pressures Min/Max (PS)
12. Decisive volume or volume for ea ch fluid (V)
13. Locations of th e connections for each fluid
14. Decisive fluid group
15. Year of manufacture
16. Serial number
17. Type
18. Manuf acturer’s n ame
1
2
3
4
18
17
16
15
14
13
12
11
10
9
8
7
6
5
1
18
15
13
14
12
8
11
10
9
6
5
4
17
7
3
TS
V
INLET → OUTLET
VOLUME
MIN./MAX.
ALLOWABLE PRESS.
→ →
STATISTICAL BASIS.
MANUFACTURER
FOR SERVICE:
PRESSURE TESTING PERFORMED ON
PRESSURE TESTED
MAX. OP. TEMP.
FLUID GROUP
YEAR OF MANUFACTURING:
MANUFACTURER:
ALLOWABLE TEMP.
MIN./MAX.
TYPE: SERIAL NUMBER:
PT
PS
Service
Year
Manufacturer
Fluid group
Inlet Outlet
Allowable press.
Allowable temp.
Volume V
Manufacturer
Serial No.
Type
Max. op. temp.
Test pressure date
WARNING
Min./Max. PS
Min./Max. TS
PT
16
Figure 1. Example of CE metallic name plate to the left and CE s ticker label name plate to
the rig ht
Docum
en t ID
Langu
age
Editi
on
8 Instruction Manual - Plate Heat Excha ngers 3490010217 EN 2016-06
