24
7. Maintenance7.1 Dismantling of ThinkTop
®
Step 1
1. Remove the ThinkTop
®
from the actuator.
2. Pull out X-ring and replace it.
Step 2
1. Untighten the three screws.
2. Pull off cover of ThinkTop
®
.
Note:
Turn banjo
connection!
Step 3
1. Untighten screws.
2. Remove solenoid valves (up to three) and replace them
with new ones.
Step 4
1. To dismantle the adapter (the lower part of the ThinkTop
®
)
from base (the middle part), unscrew the three screws.
2. Turn the lower part a little clockwise and pull.
3. Replace adapter if necessary.
Study the instructions carefully.
Handle scrap correctly.
Always keep spare X-rings in stock.
