Component Secured to Screw type Quantity Screw image
Left AlienFX
side-panel
connector
assembly
Chassis #6-32x6 2
Left AlienFX
side-panel
connector
Bracket #6-32x6 1
I/O board Chassis #6-32x6 5
Wireless card Chassis M2x3 1
Top fan Chassis #6-32x6 1
Logo board Chassis #6-32x6 1
Logo board Bracket #6-32x6 6
Solid-state
drive
System board M2x2.5 1
PCI fan Chassis M3x5.25 2
Fan shroud PCI fan M5x10 4
16
