Component Secured to Screw type Quantity Screw image
Processor
liquid-cooling
assembly
Chassis M5x10 4
Power-supply
unit
Chassis #6-32x6 4
System-board Chassis #6-32x6 9
Rear-handle
bar
Chassis #6-32x6.5 14
Front-handle
bar
Chassis #6-32x6.5 14
Bottom-handle
bar
Chassis #6-32x6.5 14
Front bezel Chassis #6-32x6 5
Rear bezel Chassis #6-32x6 4
Rear bezel Chassis M3x5 3
Base panel Chassis #6-32x6 4
17
