About your monitor | 23
Universal Serial Bus (USB) interface
This section provides informati
on about the USB ports that are available on the
monitor.
NOTE: This monitor is SuperSpeed USB 5 Gbps (USB 3.2 Gen 1)
compatible.
*Up to 2 A on USB downstream port (with battery icon) with battery charging
version-compliant devices or normal USB devices.
USB 3.2 Gen 1 (5 Gbps) upstream connector
Transfer speed Data rate Power consumption*
Super-Speed 5 Gbps 4.50 W (maximum each port)
High speed 480 Mbps 4.50 W (maximum each port)
Full speed 12 Mbps 4.50 W (maximum each port)
Pin number 9-pin side of the connector
1VCC
2D-
3D+
4GND
5SSTX-
6SSTX+
7GND
8SSRX-
9SSRX+
