Steps
1. Route the battery cable through the routing guides on the battery.
2. Connect the battery cable to the battery.
3. Adhere the tape that secures the battery cable to the battery.
4. Turn the battery over.
Next steps
1. Install the
battery.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Speakers
Removing the speakers
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image(s) indicate the location of the speakers and provides a visual representation of the removal procedure.
38
