8
CAUTION: A good flow of water must be flowing
from the end of a gun for 30 seconds, before
proceeding. Lack of water can cause damage to the
water pump and like components.
CAUTION: On a machine equipped with a trigger
gun valve, if the trigger gun valve remains in the closed
position for more than 3 minutes, water pump damage
may occur.
3. Turn the switch to the “burner” position.
CAUTION: Do not run the machine with the burner
switch in the on position when the fuel tank is empty
or with tank valves closed.This will cause damage
to the fuel pump and void warranty.
CAUTION: Do not operate with the trigger gun valve
closed for more than 3 minutes or water pump
damage may occur.
START-UP
Supersedes 08-19-05 Z08-03940E 07-05-06 Z08-03940E
Quick-Connect spray tips have fixed spray patterns that
are more consistent than those produced by an adjustable
nozzle. Each tip is color-coded for easy identification. White
(40°): produces a wide-fan spray for general cleaning and
rinsing. Green (25°): provides a narrower-fan spray for tough
stains in general cleaning applications. Yellow (15°): main-
tains a tight-fan spray with intense cleaning power for heavy-
duty cleaning and paint preparation. Red (0°): creates a
concentrated pinpoint water jet for stubborn stains on con-
crete, masonry, or steel, and for stripping paint.
♦ ELECTRICAL: Connect the machine to an electrically
grounded circuit that is fuse or circuit breaker protected.
Do not use any type of adapter. If the correct type of
receptacle is not available, have one installed by a
qualified electrician.
♦ WATER SUPPLY: This machine must have a water
supply meeting or exceeding the maximum discharge
volume specified in the PERFORMANCE section, and
a minimum water inlet pressure of 40 PSI / 0.68 BAR.
♦ LIME: Water containing large amounts of lime, calcium
or other similar materials can produce a coating on the
inside of the spray tip, impact nozzle and coil pipe.
♦ FLOAT TANK: Check the float tank (if so equipped) to
assure it is full and the float valve shuts off securely.
♦ FLOAT TANK BALL VALVE: Check the position of the
ball valve on the outlet side of the float tank (if so
equipped) that it is in the open position
♦ CHEMICAL: Use factory recommended chemicals for
best cleaning action and for extended pump life. Follow
instructions on chemical container.
1. Select temperature (if so equipped).
2. With the gun assembly in hand (on trigger gun models
hold the trigger gun valve in open position) and with a
good flow of water turn the switch to the “pump” position.
WARNING: ELECTRICAL SHOCK HAZARD
LE DANGER ELECTRIQUE DE CHOC
ADVERTENCIA: CHOQUE ELÉCTRICO
WARNING: RISK OF INJECTION OR
SEVERE INJURY. KEEP CLEAR OF
NOZZLE. DO NOT DIRECT DISCHARGE STREAM
AT PERSONS. THIS EQUIPMENT IS TO BE USED
ONLY BY TRAINED OPERATORS.
AVERTISSEMENT:RISQUE D’INJECTION ET
DE BLESSURES GRAVES. SE TENIR À
L’ÉCART DU JET. NE PAS DIRIGER LE JET DE
SOTIE VERS D’AUTRES PERSONNES CONFIER
L’UTILISATION LE JET DE SOTIE VERS D’AUTRES
PERSONNES. CONFIER L’UTILISATION DE CE
MATÉRIEL À UN OPÉRATEUR QUALIFIÉ.
ADVERTENCIA:RIESGO DE LA INYECCIÓN
O SEVERO LESIÓN. CLARO DE LA
SUBSISTENCIA DEL INYECTOR. NO DIRIJA LA
CORRIENTE DE LA DESCARGA EN LAS PERSO-
NAS. ESTO EL EQUIPO DEBE SER UTILIZADO
SOLAMENTE LOS OPERADORESENTRENADOS.
WARNING: Use of pressure washer can create puddles
and slippery surfaces.
High pressure spray could cause you to fall if you are
too close to the cleaning surface.
• Keep spray nozzle between 8 to 24 inches away from
cleaning surface.
• Operate this unit on a stable surface.
• The cleaning area should have adequate slopes and
drainage to reduce the possibility of a fall due to slippery
surfaces.
• Be extremely careful if you must use the pressure
washer from a ladder, scaffolding or any other relatively
unstable location.
• Firmly grasp spray gun with both hands when using high
pressure spray to avoid injury when gun kicks back.
