ALLEN & HEATH CQ-18T User Manual

 21
User Guide V1.1.0 Issue 1
Differences
1. Main screen keys:
Physical keys on hardware Vs Main tabs at the top of CQ-MixPad
2. Soft Keys:
Physical keys on hardware Vs buttons on CQ-MixPad
3. Location of channel bank tabs:
At the top of a CQ touchscreen Vs At the bottom left of CQ-MixPad
4. Keyboard text entry:
On-screen with hardware Vs Default method for the remote device
Some additions with CQ-MixPad are:
5. Faders are available at the bottom of Processing and FX screens.
6. Other than in the Processing screen, output selection and output level
fader are always available on the right-hand side.
Control and fine adjustment of faders in CQ-MixPad
Touch or click and drag to move faders up or down.
Keep the fader selected (keep finger on screen or click and hold) and move left or
right away from the fader to make finer adjustments when moving up or down. The
further from the fader, the finer the control.

ALLEN & HEATH CQ-18T Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	18 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	35 W
Output impedance	75 Ω
Built-in display	Yes
Compatible memory cards	SD, SDHC
Master (XLR) out	2
Number of microphone inputs	18
Video capability	-
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	242 mm
Width	346 mm
Height	89 mm
Weight	3000 g
Package depth	310 mm
Package width	430 mm
Package height	200 mm
Package weight	3800 g
