ALLEN & HEATH ZED R16 Firewire User Manual

Allen & Heath 10 ZED-R16 User Guide
SPECIFICATIONS
Operating Levels
Inputs
Mono channel (XLR) Input -6 to –60dBu for nominal (+14dBu in max)
Mono channel Line Input (Jack socket) +14 to –40dBu (+34dBu maximum)
Insert point (TRS Jack socket) 0dBu nominal +21dBu maximum
Stereo Input (Jack sockets) 0dBu nominal (control = Off to +10dB)
Stereo input (phono sockets) 0dBu nominal (control = Off to +10dB)
2 Track Input (phono sockets) 0dBu nominal +21dBu maximum
Outputs
Main (2 Track 1) L-R (XLR) +4dBu nominal. +27dBu maximum.
L-R Insert (TRS Jack socket) 0dBu nominal +21dBu maximum
2 Track 2 Outputs (Jack sockets) 0dBu nominal. +21dBu maximum.
All other analogue outputs 0 nominal +21dBu maximum
Frequency Response
Mic in to Mix L/R Out, 30dB gain +/-0.5dB 20Hz to 140kHz.
Line in to Mix L/R out 0dB gain +/-0.5dB 20Hz to 20kHz
Stereo in to Mix L/R out +/-0.5dB 20Hz to 40kHz
THD+n
Mic in to Mix L/R Out, 6dB gain 1kHz +10dBu out 0.0025%
Mic in to Mix L/R Out, 30dB gain 1kHz 0.0045%
Line in to Mix L/R out 0dB gain +10dBu 1kHz 0.003%
Stereo in to Mix L/R out 0dB gain +10dBu 1kHz 0.004%
Headroom
Analogue Headroom from nominal (0Vu) 21dB
Digital converter headroom from nominal analogue (0Vu) 16dB
Digital Performance
Analogue to Digital conversion 24bit 114dB dynamic range (A wtd)
Digital to Analogue conversion 24bit 118dB dynamic range (A wtd)
Sample Rate 44.1, 48, 88.2, 96kHz
Noise
Mix Noise, LR out, 16 channels routed, Ref +4dBu, 22-22kHz -88dB (-84dBu)
Mix Noise, Aux 1-4 out, sends minimum, masters at unity 22-22kHz -86dBu
Mic Pre EIN @ 60dB gain 150R input Z 22-22kHz -128.5dBu
MIDI
Fader and Rotary values 0-127
MIDI switches Note on/note off
Transport control MIDI Machine Control
MIDI channel Default = 16. User settable
Power consumption 48W
