Allen & Heath 43 ZED-R16 User Guide
System Requirements (For SONAR LE)
(For running SONAR LE on a Windows computer. The system requirements for connecting to ZED-R16 are docu-
mented separately)
SONAR LE Installation.
Put disk into CD or DVD ROM drive and follow instructions on screen.
SONAR LE Audio Configuration with ZED-R16.
To configure your SONAR LE software to communicate
audio to and from your ZED-R16 mixing console, follow the
sequence below.
Ensure the Driver software is installed on your computer.
Please refer to the section titled Installing Drivers.
Ensure the ZED-R16 is powered on.
Connect the FireWire lead from the computer to either
FireWire port on ZED-R16.
First check that your computer has recognised
the connection of the ZED-R FireWire device by clicking
Settings/Control Panel/Sounds and Audio Devices/Audio.
ZED R Audio should appear as an option in the drop-down
menu for Sound playback devices as shown on the right:
It is also a good idea to select “No Sounds” in the
Sounds window so you don’t get the Windows beeps etc.
through your monitors.
System Require-
ments
Minimum Recommended
Operating System Windows XP Windows XP/Vista/Vista x64
Processor Speed Intel® Pentium® 4 1.3 GHz,
or AMD™ Athlon XP 1500+
or higher
Intel® Pentium® 4 2.8 GHz
[EM64T], or AMD™ Athlon 64
2800+or higher
RAM 256 MB 1 GB or higher
Graphics (resolution,
color depth)
1024 x 768, 16-bit colour
1280 x 960, 32-bit colour
Hard Disk Space 100 MB for core program 2 GB for program and content
Hard Disk Type
Any
EIDE/Ultra DMA (7200 RPM) or
SATA
MIDI Interface
Windows-compatible
Windows-compatible
Audio Interface
Windows-compatible
WDM- or ASIO-compatible, includ-
ing WaveRT for Vista
Optical Drive
DVD-ROM, DVD+/-R, or DVD+/-RW for installation, CD-R or CD-
RW capability required for CD audio disc burning
