ALLEN & HEATH ZED R16 Firewire User Manual

Allen & Heath 25 ZED-R16 User Guide
DIGITAL INPUT & OUTPUT CONFIGURATIONS
MONO CHANNELS 1 -16 ANALOGUE I/O
1-8 9-16 1-8 9-16
A-D A-D D-A D-A
CODEC
17-1817-18
STEREO MASTER
FIREWIRE
STREAMING
CONTROLLER
ADAT INADAT OUT
1-8 9-16 1-8 9-16
DAW
DEVICE CHANNELS 1-16 = MIXER CH 1-16
DEVICE CHANNELS 17-18 = MIXER DIG L-R
DEVICE CHANNELS 19-26 = ADAT 1-8
(ADAT CHANNELS ACCESSED VIA DAW)
SAMPLE RATES 44.1 & 48kHz
ADAT
FIREWIRE
MONO CHANNELS 1 -16 ANALOGUE I/O
1-8 9-16 1-8 9-16
A-D A-D D-A D-A
CODEC
17-1817-18
STEREO MASTER
FIREWIRE
STREAMING
CONTROLLER
DEVICE CHANNELS 1-16 = MIXER CH 1-16
SAMPLE RATEs 88.2 & 96kHz
ADAT
FIREWIRE
MONO CHANNELS 1 -16 ANALOGUE I/O
1-8 9-16 1-8 9-16
A-D A-D D-A D-A
CODEC
17-1817-18
STEREO MASTER
FIREWIRE
STREAMING
CONTROLLER
SAMPLE RATE 44.1 or 48kHz
ADAT
FIREWIRE
ADAT INADAT OUT
1-8
9-16
1-8
9-16
ADAT INADAT OUT
1-8
9-16
1-8
9-16
SYNC CONTROL
DAW
MONO CHANNELS 1 -16 ANALOGUE I/O
1-8 9-16 1-8 9-16
A-D A-D D-A D-A
CODEC
17-1817-18
STEREO MASTER
FIREWIRE
STREAMING
CONTROLLER
SAMPLE RATE 44.1 or 48kHz
ADAT
FIREWIRE
ADAT IN
ADAT OUT
1-8
9-16
1-8
9-16
SYNC CONTROL
COMPUTER USED TO SWITCH CLOCK SYNC SOURCE
ADAT RECORDER
ADAT RECORDER
ZED-R16
DAW
1 FireWire mode 44.1 or 48kHz
3 ADAT mode 44.1 or 48kHz
2 FireWire mode 88.2 or 96kHz
4 ADAT mode 44.1 or 48kHz
FireWire used to control sync source
INTERNAL SYNC
SYNC EITHER INTERNAL OR ADAT IN
ZED-R16
DAW
ZED-R16
ADAT EQUIPMENT
ZED-R16
ADAT EQUIPMENT
+ PC/MAC
DIGITAL I/O CONFIGURATIONS:
The following four set-up configuration diagrams show a schematic representation of the ZED-R16 digital I/O section
connected to the recording/playback equipment. Note the FireWire channel differences at higher sample rate settings.
