ALLEN & HEATH ZED R16 Firewire User Manual

Allen & Heath 41 ZED-R16 User Guide
MODES OF OPERATION
MIC
INSERT
LINE
48V
1
IN
-15 +15
60 40-14 6
30
40
50
0
20
GAIN
HPF
100Hz
HM
0.8
6
2k
700
400Hz
1k
6k
18k
4k
-15 +15
Q
F
G
LM
0.8
6
120
30
18Hz
60
600
1k
300
-15 +15
Q
F
G
-15
LF
+15
80Hz
HF
12k
EQ IN
+6
AUX1
PRE
OO
+6
AUX2
PRE
OO
+6
AUX3
POST
OO
+6
AUX4
POST
OO
PAN
L R
=
MUTE
PFL
HI
SIG
L-R
Post-EQ
5
5
0
OO
10
DIG RET
DIG RET
Pre-INS
Post-EQ
FADER
=MIDI
10
DIG SND
1
1
1
ADC
DIGITAL SIGNAL
(FIREWIRE OR ADAT)
PRESS DIG SEND = POST EQ AND DIG RETURN = PRE-INSERT
DIGITAL SEND FROM
AFTER EQ
The post EQ signal is
sent back to the DAW.
DIGITAL INPUT = PRE INSERT
The digital input from the DAW
replaces the signal from the
channel pre-amp
DAC
EXTREME FLEXIBILITY—ANALOGUE PLUG-INS!
You can even use the EQ in the ZED-R16 channel as an analogue plug-in for your Digital Audio Workstation!
To do this press both the DIG RET = PRE INS to source the channel from your DAW and the DIG SND = POST EQ,
so the output of the EQ goes back to the DAW. You may need to create a new track in your software application for
the equalised audio, otherwise a feedback loop could easily be created between the ZED-R16 and the DAW.
Create a new track in the DAW to return the EQ’d
signal, arm the track and record it as required.
Monitor the post-EQ signal either using the channel
PFL or the SOLO function in your DAW, returning the
master stereo track to the ZED-R16 in the master
section.
