18 1732E ArmorBlock 2-Port EtherNet/IP Modules with QuickConnect
Publication 1732E-IN010C-EN-E - June 2013
Network status Off The device is not initialized or the module does not
have an IP address.
Flashing green The device has no CIP connections.
The device has an IP address, but no CIP connections
are established.
Green The device is online, has an IP address, and CIP
connections are established.
Flashing red One or more connections have timed out.
Red The module has detected that its IP address is already
in use.
Flashing red/green The module is performing a powerup self-test.
Network link status Off No link established.
Green Link established on indicated port at 100 Mbps.
Flashing green Link activity present on indicated port at 100 Mbps.
Yellow Link established on indicated port at 10 Mbps.
Flashing yellow Link activity present on indicated port at 10 Mbps.
Power status Off No power to device or input not valid.
Green Power applied to device.
Digital output status Off Output not energized.
Yellow Output energized and output power applied.
Flashing yellow Output energized and no output power.
Red
(1)
Output shorted.
Flashing red Output open load.
Digital input status Off No valid input.
Yellow Valid input.
Red
(1)
Sensor source voltage shorted.
Flashing red Sensor source open wire.
(1)
Only diagnostic modules 1732E-12X4M12QCDR and 1732E-12X4M12P5QCDR have red I/O status LED indicators.
In non-QuickConnect mode, the Module Status LED indicator flashes red
and green for a maximum 5 s while the module completes its POST
(Power-On Self Test).
Indicator Status for Modules
Status Description
