6 1732E ArmorBlock 2-Port EtherNet/IP Modules with QuickConnect
Publication 1732E-IN010C-EN-E - June 2013
Install the Module
To install the module:
• Set the network address
•Mount the module
• Connect the I/O, Network and Auxiliary cables to the module.
Set the Network Address
The I/O block ships with the rotary switches set to 999 and DHCP enabled.
To change the network address, you can do one of the following:
• adjust the switch on the front of the module.
• use a Dynamic Host Configuration Protocol (DHCP) server, such as Rockwell
Automation BootP/DHCP.
• retrieve the IP address from nonvolatile memory.
The I/O block reads the switches first to determine if the switches are set to a valid
number. To set the network address:
1. Rotate the three (3) switches on the front of the module using a small
blade screwdriver.
2. Line up the small notch on the switch with the number setting you wish to use.
Valid settings range from 001…254.
3. Cycle power.
1732E-16CFGM12P5QCR 16 channel 24V DC self-configurable digital
I/O dual-port Ethernet module with
QuickConnect
Dual D-code
M12
Dual 5-pin
mini
1732E-16CFGM12QCWR 16 channel 24V DC self-configurable digital
I/O dual-port Ethernet metal WeldBlock
module with QuickConnect
Dual D-code
M12
Dual 4-pin
mini
1732E-16CFGM12P5QCWR 16 channel 24V DC self-configurable digital
I/O dual-port Ethernet metal WeldBlock
module with QuickConnect
Dual D-code
M12
Dual 5-pin
mini
Catalog Number Description Network
Connector
Auxiliary
Power
