18 POINT I/O 4 Channel IO-Link Master Module
Publication 1734-IN043A-EN-E - September 2015
POINT I/O 4 Channel IO-Link Master Module 1734-4IOL – Standard Digital Input
Attribute Value
On-state voltage, min 11V DC
On-state current, min 2.0 mA
On-state current, max 7.0 mA
Off-state voltage, max 5V DC
Off-state current, min 1.5 mA
Input filter
ON to OFF
OFF to ON
Each input independently settable in 1 ms intervals.
Default value is 1 ms.
0...65 ms
0...65 ms
POINT I/O 4 Channel IO-Link Master Module 1734-4IOL – Standard Digital Output
Attribute Value
On-state voltage, min 19.2V DC
On-state voltage, max 28.8V DC
On-state voltage, nom 24V DC
On-state voltage drop, max 0.9V DC
On-state current, max 150 mA
Off-state current leakage, max 0.5 mA
Module current (all outputs), max 600 mA
Surge current, max 0.3 A for 10 ms, repeatable every 3 s
