6 POINT I/O 4 Channel IO-Link Master Module
Publication 1734-IN043A-EN-E - September 2015
POINT I/O 4 Channel IO-Link Master Module with 1734-TOP, 1734-TOPS,
1734-TOP3, or 1734-TOP3S One-Piece Terminal Base
Description Description
1 Module locking mechanism 6 Terminal base
2 Slide-in writable label 7 Interlocking side pieces
3 Insertable I/O module 8 Mechanical keying (orange)
4 Removable terminal block (RTB) handle 9 DIN rail locking screw (orange)
5 Removable terminal block 10 Module wiring diagram
Description Description
1 Module locking mechanism 6 Interlocking side pieces
2 Slide-in writable label 7 Mechanical keying (orange)
3 Insertable I/O module 8 DIN rail locking screw (orange)
4 Terminal block handle 9 Module wiring diagram
5 One-piece terminal base
24V DC
SIO
IO
LINK
Module
Status
Network
Status
1734-4IOL
0
0
1
1
2
2
3
3
NODE:
