Allen-Bradley 1734-OE4C

14 POINT I/O 4 Channel Analog Current Output Module
Publication 1734-IN034C-EN-E - August 2016
Wire the Module
Wiring Diagram
WARNING: If you connect or disconnect wiring while the field-side power is
on, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
Channel Current Common Supply
0046
11
5 7
22
33
DC power is provided by the internal power bus.
1734
OE4C
44352
Output 0 connection 0 Output 1 connection 1
Output 2 connection 2 Output 3 connection 3
C 4 5 C
V 6 7 V
C = Common
V = Supply
In = Output channel
Chas Gnd = Chassis Ground
C = Common
V = 24V DC supply
4-wire
AC or DC
Out 0 Out 1
3
5
7
0
1
2
4
6
Out 2 Out 3
Current
output
device
Current
output
device
2-wire
Chas Gnd
CC
VV
