Allen-Bradley 1734-OE4C

POINT I/O 4 Channel Analog Current Output Module 7
Publication 1734-IN034C-EN-E - August 2016
Description Description
1 Module locking mechanism 6 Mounting base – 1734-TB, 1734-TBS
2 Slide-in writable label 7 Interlocking side pieces
3 Insertable I/O module 8 Mechanical keying (orange)
4 Removable Terminal Block (RTB) handle 9 DIN rail locking screw (orange)
5 RTB with screw or spring clamp 10 Module wiring diagram
Description Description
1 Module locking mechanism 6 Interlocking side pieces
2 Slide-in writable label 7 Mechanical keying (orange)
3 Insertable I/O module 8 DIN rail locking screw (orange)
4 Handle 9 Module wiring diagram
5 One-piece terminal base with screw or
spring clamp – 1734-TOP, 1734-TOPS
1
9
8
7
6
2
4
5
44221
3
