Allen-Bradley 1756-IA8D User Manual

Rockwell Automation Publication 1756-UM058G-EN-P - November 2012 243
1492 IFMs for Digital I/O Modules Appendix G
1756-IV32 1492-IFM40F Feed-through Standard 1492-CABLExZ
(x=cable length)
1492-IFM40F-2 Extra terminals
1492-IFM40F-3 3-wire sensor type input devices
1492-IFM40D24 Status-indicating Standard with 24V AC/DC status indicators
1492-IFM40D24A-2 24V AC/DC status indicators
1492-IFM20D24-2 24V AC/DC status indicators and extra terminals for inputs
1492-IFM20D24-3 3-wire sensor with 24V AC/DC status indicators
1756-OA8 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20DS120-4 Status-indicating Isolated with 120V AC status indicators and four terminals per output 1492-CABLExW
(x=cable length)
1492-IFM20F-FS-2 Fusible Isolated with 120V AC/DC with extra terminals for outputs
1492-IFM20F-FS120-2 Isolated with extra terminals with 120V AC/DC blown fuse indicators for outputs
1492-IFM20F-FS120-4 Isolated with four terminals with 120V AC blown fuse indicators for outputs
1492-IFM20F-FS240-4 Isolated with four terminals with 240V AC/DC blown fuse indicators for outputs
1756-OA8D 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20DS120-4 Status-indicating Isolated with 120V AC status indicators and four terminals per output 1492-CABLExV
(x=cable length)
1492-IFM20F-FS-2 Fusible Isolated 120V AC/DC with extra terminals for outputs
1492-IFM20F-FS120-2 Isolated with extra terminals with 120V AC/DC blown fuse indicators
1492-IFM20F-FS120-4 Isolated with four terminals per output and 120V AC/DC blown fuse indicators
1756-OA8E 1492-IFM20F Feed-through Standard 1492-CABLExU
(x=cable length)
1492-IFM20FN Narrow standard
1492-IFM20F-2 Extra terminals
1492-IFM20DS120-4 Status-indicating Isolated with 120V AC status indicators and four terminals per output 1492-CABLExV
(x=cable length)
1492-IFM20F-FS-2 Fusible Isolated 120V AC/DC with extra terminals for outputs
1492-IFM20F-FS120-2 Isolated with extra terminals with 120V AC/DC blown fuse indicators
1492-IFM20F-FS120-4 Isolated with four terminals per output and 120V AC/DC blown fuse indicators
Table 65 - IFMs and Prewired Cables (continued)
I/O Cat. No. IFM Cat. No. IFM Type IFM Description Prewired Cable
