248 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Appendix G 1492 IFMs for Digital I/O Modules
The following tables describe the prewired, module-ready cables and connectors
available for your ControlLogix digital I/O modules.
Table 66 - Module-Ready Cables
Cat. No.
(1)
No. of Conductors Conductor Size Nominal Outer Diameter RTB at the I/O Module End
1492-CABLExU 20 0.326 mm
2
(22 AWG) 9.0 mm (0.36 in.) 1756-TBNH
1492-CABLExV
1492-CABLExW
1492-CABLExX
1492-CABLExY 40 11.7 mm (0.46 in.) 1756-TBCH
1492-CABLExZ
(1) Cables are available in lengths of 0.5 m, 1.0 m, 2.5 m, and 5.0 m. To order, insert the code for the desired cable length into the catalog number in place of the x: 005=0.5 m, 010=1.0 m, 025=2.5 m,
050=5 m. Build-to-order cable lengths are also available.
Table 67 - Module Connectors
Cat. No.
(1)
No. of Conductors Conductor Size Nominal Outer Diameter RTB at the I/O Module End
1492-CABLExTBNH 20 0.823 mm
2
(18 AWG) 11.4 mm (0.45 in.) 1756-TBNH
1492-CABLExTBCH 40
(2)
14.1 mm (0.55 in.) 1756-TBCH
(1) Cables are available in lengths of 0.5 m, 1.0 m, 2.5 m, and 5.0 m. To order, insert the code for the desired cable length into the catalog number in place of the x: 005=0.5 m, 010=1.0 m, 25=2.5 m,
050=5 m. Build-to-order cable lengths are also available.
(2) Four conductors are not connected to the RTB.
