Allen-Bradley 1769-L33ER

Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012 3
Where to Start
Follow the path that matches your hardware and network configuration.
PORT
MOD
NET B
NET A
STS
Create a Logix
Designer Project
Prepare the CompactLogix 5370 L3
Controller Hardware
Prepare the Computer and Load
Controller Firmware
Configure the EtherNet/IP
Network
Configure the DeviceNet
Network
Required
Required
Optional
Required
page 17
page 33
page 49 page 53
page 63
Optional
POINT I/O
™
Modules
Kinetix
®
350
Drive
PowerFlex
®
40
Drive
PowerFlex 70
Drive
PanelView
™
Plus Terminal
For more information on using each optional
device, see Table 1 on page 12
.
