Preface
Parts List
Tab le 3 lists the hardware used in this quick start.
For example, if you do not intend to use a DeviceNet network to complete tasks described in
some publications listed in Table 1
, you do not need the hardware related to installing a
DeviceNet network.
Specific hardware requirements are listed at the beginning of each chapter.
Table 3 - Parts Used with This Quick Start
Quantity Cat. No. Description
2 or 3 N/A DIN rail (steel, not aluminum)
1 One of the following:
• 1769-L30ER
• 1769-L30ERM
• 1769-L30ER-NSE
• 1769-L33ER
• 1769-L33ERM
• 1769-L36ERM
CompactLogix 5370 L3 controllers
The tasks described in this publication use a 1769-L36ERM controller.
1 1769-PA4 Compact I/O power supply
1 1769-OB16 Compact 16-point 24V DC sourcing output module
1 1769-ECR Compact I/O right end cap/terminator
1 1783-EMS08T
Stratix
™
6000 Ethernet managed switche
1 External power supply for Stratix 6000 Ethernet managed switch
1 1585J-M8PBJM-2 RJ45-to-RJ45 patchcord Ethernet cables
1 1769-SDN Compact I/O DeviceNet scanner
1 1485C-P1E75
KwikLink
™
flat cable, 75 m (246 ft)
2 1485A-T1E4 KwikLink terminator/resistor
1 1485P-P1E4-R5 KwikLink sealed micro connector
1 1485K-P1F5-C KwikLink QD cordset micro right-angle male
1 1606-XLDNET8 DeviceNet power supply
1 1485T-P1E4-B1 KwikLink power tap module
