18 Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012
Chapter 1 Prepare the CompactLogix 5370 L3 Controller Hardware
What You Need
Tab le 4 lists the hardware components used in this chapter. The parts listed in this table are done
so with the assumption that you will install an EtherNet/IP and DeviceNet network.
Table 4 - Parts Used with This Quick Start
Quantity Cat. No. Description
1 or more N/A DIN rail (steel, not aluminum)
1 One of the following:
• 1769-L30ER
• 1769-L30ERM
• 1769-L30ER-NSE
• 1769-L33ER
• 1769-L33ERM
• 1769-L36ERM
CompactLogix 5370 L3 controller
The tasks described in this publication use a
1769-L36ERM controller.
1 1769-PA4 Bus power supply
1 1606-XLDNET8 DeviceNet network power supply
1 1769-ECR Compact I/O end cap/terminator
1 or more 1585J-M4TBJM-2 Ethernet cable (straight-through)
1 1783-EMS08T Stratix 6000 Ethernet managed switch
1 External power supply for Stratix 6000 Ethernet
managed switch
1 1769-SDN DeviceNet communication module
1 1769-OB16 Compact I/O output module
1 1485C-P1E75 KwikLink flat cable, 75 m (246 ft)
2 1485A-T1E4 KwikLink terminator/resistor
2 or more 1485P-P1E4-R5 KwikLink sealed micro connector
1 or more 1485K-P1F5-C KwikLink QD Cordset Micro right-angle male
1 1485T-P1E4-B1 KwikLink power tap module
To Next Page
