Prepare the CompactLogix 5370 L3 Controller Hardware Chapter 1
Follow These Steps
2 (Rear)
1 (Front)
Install the Secure
Digital Card
Assemble the
System
Make Network
Connections
page 21
Wire Power page 32
page 23
page 26
Install the
Networks
page 20
