Allen-Bradley 1794-IE8 Series B User Manual

4–12 Writing Configuration to and Reading Status from Your Module with a Remote I/O Adapter
Publication 17946.5.2 - May 1996
Definition
Decimal Bit
(Octal Bit)
Word
Words 4
and 5
Not used - set to 0.
Word 6
Bits 00-14
(00-16)
Channel 0 Safe State analog value - 12bit left justified two's complement number;
unused lower bits are zero; 420mA uses all 16 bits.
Word
6
Bits 15 (17) Channel 0 Safe State analog data sign bit.
Word 7
Bits 00-14
(00-16)
Channel 1 Safe State analog value - 12bit left justified two's complement number;
unused lower bits are zero; 420mA uses all 16 bits.
Word
7
Bits 15 (17) Channel 1 Safe State analog data sign bit.
In this chapter you learned how to configure your module’s features
and enter your data.
Chapter Summary
