Allen-Bradley 1794-IE8 Series B User Manual

5–8 How Communication Takes Place and I/O Image Table Mapping with the DeviceNet Adapter
Publication 17946.5.2 - May 1996
DefinitionDecimal BitWord
Write Word 5
Bits 00-03
Output Enable bits. Bit 00 corresponds to input 0, bit 01
corresponds to input 1, bit 02 corresponds to input 2, and bit 03
corresponds to input 3. These bits must be set to 1.
Bits 0415 Not used - set to 0.
Bits 00-03
Full range bits (F) for individual channels - Bit 00 corresponds
to output channel 0, bit 01 corresponds to output channel 1,
and so on. Refer to range selection above.
Write Word 6
Bits 0407 Not used - set to 0.
Write Word 6
Bits 08-11
Configure select bits (C) for individual channels - Bit 08
corresponds to output channel 0, bit 09 corresponds to output
channel 1, and so on. Refer to range selection above.
Bits 1215 Not used - set to 0.
Write Word 7 Bits 00-15 Not used - set to 0.
Write Word 8 Bits 00-15 Not used - set to 0.
Write Word 9 Bits 00-15 Not used - set to 0.
Write Word 10 Bits 00-15 Not used - set to 0.
Write Word 11 Bits 00-15 Not used - set to 0.
Write Word 12 Bits 00-15 Not used - set to 0.
Write Word 13 Bits 00-15 Not used - set to 0.
Write Word 14 Bits 00-15 Not used - set to 0.
