Specifications and Dimensions A-7
Contactor Ratings
The table below lists contactor examples recommended for use with
the Ultra3000 (460V) drives.
Power Dissipation Specifications
Use the following table to size an enclosure and calculate required
ventilation for the Ultra3000. Typical heat losses run approximately
one-half maximum power losses. The maximum power losses are
shown below.
Catalog Number
Input
Voltage
Contactor
2098-DSD-HV030x-xx
460V
100-C23x10 (AC Coil)
100-C23Zx10 (DC Coil)
2098-DSD-HV050x-xx
100-C30x10 (AC Coil)
100-C30Zx10 (DC Coil)
2098-DSD-HV100x-xx
100-C37x10 (AC Coil)
100-C37Zx10 (DC Coil)
2098-DSD-HV150x-xx
100-C43x10 (AC Coil)
100-C43Zx10 (DC Coil)
2098-DSD-HV220x-xx
100-C60x10 (AC Coil)
100-C60Zx10 (DC Coil)
Catalog Number
Maximum Loss
Watts
Catalog Number
Maximum Loss
Watts
2098-DSD-005x-xx 48 2098-DSD-HV030x-xx 175 + dissipative shunt
2098-DSD-010x-xx 48 2098-DSD-HV050x-xx 175 + dissipative shunt
2098-DSD-020x-xx 50 2098-DSD-HV100x-xx 350 + dissipative shunt
2098-DSD-030x-xx 150 + dissipative shunt 2098-DSD-HV150x-xx 350 + dissipative shunt
2098-DSD-075x-xx 300 + dissipative shunt 2098-DSD-HV220x-xx 600 + dissipative shunt
2098-DSD-150x-xx 500 + dissipative shunt
