Appendix

Interconnect Diagrams

Chapter Objectives

This appendix contains the following interconnect diagrams:

• Power Interconnect Diagrams

• Shunt Module Interconnect Diagrams

• Ultra3000/Motor Interconnect Diagrams

• Control String Examples (120V ac)

• Controlling a Brake Example

• Ultra3000 to Logix Cable and Interconnect Diagrams

• Ultra3000 to IMC-S Compact Cable and Interconnect Diagram
