Publication 2098-IN003E-EN-P — April 2004
Catalog Numbers and Accessories C-3
AC Line Filters
Use the following table to identify the AC Line Filter for your
application.
External Shunt Kits
Use the following table to identify the external shunt kit for your
application.
1
Bonitron part number. For more information contact Bonitron, Inc. 521 Fairground Court, Nashville, TN 37211.
Tel: (615) 244-2825. www.BONITRON.com.
AC Line Filter Description
AC Line Filter Fuse
Block
Catalog Number
AC Line Filter (single-phase, 240V)
6 Amp 2090-UXLF-106
10 Amp 2090-UXLF-110
23 Amp 2090-UXLF-123
32 Amp 2090-UXLF-132
36 Amp 2090-UXLF-136
50 Amp 2090-UXLF-150
AC Line Filter (three-phase, 240V)
36 Amp 2090-UXLF-336
50 Amp 2090-UXLF-350
70 Amp 2090-UXLF-370
AC Line Filter (three-phase, 480V)
23 Amp 2090-UXLF-HV323
30 Amp 2090-UXLF-HV330
50 Amp 2090-UXLF-HV350
Shunt Module
Catalog Number:
Description: Ultra3000 Drive Compatibility:
2090-UCSR-A300 Active Shunt Module (300W) 2098-DSD-005, -010, -020
9101-1183 Passive Shunt Module (200W) 2098-DSD-030
2090-UCSR-P900
Passive Shunt Module (900W)
2098-DSD-075, -150
2090-SR120-09 2098-DSD-HV030 and -HV050
2090-SR040-09
2098-DSD-HV100
2090-SR040-18 Passive Shunt Module (1800W)
M3575R-H27B0,C
1
Passive Shunt Module (900W)
2098-DSD-HV150
M3575R-H27BF,C
1
Passive Shunt Module (1800W)
M3575R-H33BF,C
1
Passive Shunt Module (3600W) 2098-DSD-HV220
