Rockwell Automation Publication 2099-UM001D-EN-P - December 2012 159
Specifications and Dimensions Appendix A
Figure 70 - 2099-BM09-S and 2099-BM10-S Approximate Dimensions
286.7
(11.29)
644.5
(25.37)
2099-BM09
6.5
(0.26) 2X
31.9
(1.26)
20.4
(0.80) 2X
300.0
(11.81)
259.1
(10.20) 2X
Ø 15.0
(0.59) 2X
225.0
(8.86)
37.5
(1.48)
Ø 6.5
(0.26) 2X
12.0
(0.47)
644.5
(25.37)
7.0
(0.28)
625.0
(24.61)
690.3
(27.18)
2099-BM10
Ø 34.9
(1.37) 2X
60.4
(2.38)
159.5
(6.28)
31.9
(1.26)
85.1
(3.35)
65.0
(2.56) 2X
130
(5.12)
170
(6.69)
24.5
(0.96) 2X
45.5
(1.79)
Ø 22.2 (0.87)
Ø 62.7 (2.47) 2X
70
(2.75)
35
(1.38)
31.8
(1.25)
153.5
(6.04) 2X
Ø 34.9
(1.37)
Ø 22.2
(0.87) 3X
Ø 62.7
(2.47) 2X
34.1
(1.34)
22.4
(0.88)
128.1
(5.04)
53.0
(2.08) 2X
104.3
(4.10)
Dimensions are in millimeters (inches)
Important: Additional clearance below the connector is
necessary to provide the recommended cable bend radius.
