160 Rockwell Automation Publication 2099-UM001D-EN-P - December 2012
Appendix A Specifications and Dimensions
Figure 71 - 2099-BM11-S and 2099-BM12-S Approximate Dimensions
Ø 18.0
(0.71) 2X
8.5
(0.33) 2X
300.0
(11.81)
49.6
(1.95)
7.9
(0.31)
850.0
(33.46)
824.0
(32.44)
14.5
(0.04)
30.0
(1.18)
360.6
(14.20) 2X
8.5
(0.33) 2X
399.2
(15.72)
849.97
(33.46)
282.8
(11.13)
977.1
(38.47)
Ø 34.9
(1.37)
Ø 22.2 (0.87) 4X
Ø 62.7 (2.47) 2X
73.8
(2.90)
36.9 (1.45) 4X
148.4
(5.84)
31.69 (1.25)
45.0
(1.77)
22.0 (0.86) 2X
128
(5.04)
100
(3.94)
150 (5.90) 2X
200 (7.87)
151.7
(5.97)
67.2
(2.64)
Dimensions are in millimeters (inches)
Important: Additional clearance below the connector is
necessary to provide the recommended cable bend radius.
