126 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix A Supplemental Drive Information
Control Outputs
Keypad
Communication
Specification
Relay Quantity: (2) Programmable Form C
Specification
Resistive Rating:
Inductive Rating:
3.0 A @ 30V DC, 3.0 A @ 125V, 3.0 A @ 240V AC
0.5 A @ 30V DC, 0.5 A @ 125V, 0.5 A @ 240V AC
Optional Relay
Card
Quantity: (6) Optional Programmable Form A
(Not available for Frame C drives)
Specification
Resistive Rating:
Inductive Rating:
0.1 A @ 30V DC Class II circuits, 3.0 A @ 125V, 3.0 A @ 240V AC
0.1 A @ 30V DC Class II circuits, 3.0 A @ 125V 3.0 A @ 240V AC
Opto Quantity: (1) Programmable
Specification: 30V DC, 50 mA Non-inductive
Analog Quantity: (2) Non-Isolated, 0-10V or 4-20mA
Specification
Resolution:
0 to 10V DC Analog:
4-20mA Analog:
10-bit
1k ohm minimum
525 ohm maximum
Specification
Display: Integral 2 line by 16 character LCD with (5) LED Indicators
Language: English, Français, Español, Italiano, Deutsch, Português, Nederlands
Specification
Type: Serial (RS485)
Supported
Protocols
(Standard):
Drive Serial Interface (DSI)
Modbus RTU
Metasys N2
P1 - Floor Level Network (FLN)
Supported
Protocols
(Optional):
BACnet
DeviceNet
EtherNet/IP
PROFIBUS DP
ControlNet
LonWorks
Software
(Optional): Windows Based Pocket PC/Windows Mobile 2003
