Input Power Connections
Figure 16 - Frame C, D, and E Connections
Figure 17 - Frame F Connections
Note: Frames G and H do not support single-phase operation.
Input Protection
Three Phase Input
T
S
R
Input Protection
Single Phase Input
T
S
R
Input Protection
Three Phase Input
T
S
R
Input Protection
Single Phase Input
T
S
R
