Rockwell Automation Publication 22C-UM001J-EN-E - January 2017 139

Accessories and Dimensions Appendix B

Figure 19 - PowerFlex 400 Frame D Drive

Dimensions are in millimeters and (inches)

226.0 (8.90)250.0 (9.84)

206.1 (8.11)

383.4

(15.09)

436.2

(17.17)

71.6 (2.82)

132.0 (5.20)

175.5 (6.91)

192.0 (7.56)

156.3

(6.15)

132.7

(5.22)

167.4

(6.59)

∅ 22.2

(0.87)

∅ 42.0

(1.65)

∅ 9.0

(0.35)
