150 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017

Appendix B Accessories and Dimensions

Figure 28 - Remote (Panel Mount) Small HIM

Dimensions are in millimeters and (inches)

Catalog Number: 22-HIM-C2S

(3.66)

(0.98)

180

(7.09)

154

(6.06)

(3.03)

23.5

(0.93)

(2.64)

(2.36)

19.1

(0.75)

4.8

(0.19)
