4 Rockwell Automation Publication 5069-IN003E-EN-P - October 2018

Compact 5000 I/O EtherNet/IP Adapters

IEC Hazardous Location Approval

The following applies to products with IECEx certification: Such modules:

• Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and for short

periods. Such locations correspond to Zone 2 classification to IEC 60079-0.

• The type of protection is "Ex nA IIC T4 Gc" according to IEC 60079-15.

• The 5069-AEN2TR EtherNet/IP adapter complies to standards IEC 60079-0:6th Edition, IEC-60079-15:4th Edition when used at or below 125V AC, reference IECEx certificate

number IECEx UL 15.0007X.

• The 5069-AENTR and 5069-AENTRK EtherNet/IP adapter complies to standards IEC 60079-0:6th Edition, IEC-60079-15:4th Edition, reference IECEx certificate number IECEx

UL 16.0124X.

• May have catalog numbers followed by a “K” to indicate a conformal coating option

WARNING: Special Conditions for Safe Use:

• This equipment is not resistant to sunlight or other sources of UV radiation.

• This equipment shall be mounted in an ATEX/IECEx Zone 2 certified enclosure with a minimum ingress protection rating of at least IP54 (as defined in

EN/IEC 60529) and used in an environment of not more than Pollution Degree 2 (as defined in EN/IEC 60664-1) when applied in Zone 2 environments. The

enclosure must be accessible only by the use of a tool.

• This equipment shall be used within its specified ratings defined by Rockwell Automation.

• Provision shall be made to prevent the rated voltage from being exceeded by transient disturbances of more than 140% of the rated voltage when applied in

Zone 2 environments.

• The instructions in the user manual shall be observed.

• Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this

product.

• Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous.

• Earthing is accomplished through mounting of modules on rail.

• Devices shall be used in an environment of not more than Pollution Degree 2.

• The equipment must be used only with ATEX/IECEx certified Rockwell Automation backplanes.

• When installed in a non-hazardous area, the equipment may alternatively be installed in a controlled environment that provides equivalent protection.

• 5069-AEN2TR EtherNet/IP adapter only — The USB port is intended for temporary local programming purposes only and not intended for permanent

connection. Do not use the USB port in hazardous locations.

Prevent Electrostatic Discharge

ATTENTION: This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when

you handle this equipment:

• Touch a grounded object to discharge potential static.

• Wear an approved grounding wriststrap.

• Do not touch connectors or pins on component boards.

• Do not touch circuit components inside the equipment.

• Use a static-safe workstation, if available.

• Store the equipment in appropriate static-safe packaging when not in use.

Electrical Safety Considerations

ATTENTION:

• SELV-listed supplies must be used for MOD and SA power if there are Functional Safety modules connected to the Compact 5000 I/O system.

• 5069-AEN2TR EtherNet/IP adapter only:

– Do not wire more than 1 conductor on any single RTB terminal.
