6 Rockwell Automation Publication 5069-IN003E-EN-P - October 2018
Compact 5000 I/O EtherNet/IP Adapters
Install a Compact 5000 I/O System
Before you install the adapter, verify that you have the following:
System Planning
Follow these rules when planning your system configuration:
• 5069-AEN2TR adapter only — You must mount the DIN rail
horizontally.
Rockwell Automation does not support a Compact 5000 I/O
system that is installed vertically if it uses a 5069-AEN2TR
adapter.
• The adapter is the left-most component in the bank.
• Local Compact 5000 I/O modules are installed to the right of
the adapter.
• The adapter can communicate with as many as 31 local I/O
modules.
• Before powerup, verify that the end cap is installed on the
right-most Compact 5000 I/O module in the system.
Spacing
Maintain spacing from enclosure walls, wireways, and adjacent
equipment. Consider the following:
• 5069-AEN2TR adapter - You must mount the DIN rail
horizontally.
• 5069-AENTR and 5069-AENTRK adapters - You can mount
the DIN rail horizontally or vertically.
Components Needed to Install a Compact 5000 I/O
EtherNet/IP Adapter
Component Description
Removable
Term inal
Blocks (RTB)
One of the following RTB types for each power type:
5069-AEN2TR
•MOD power (system-
side power)
– 5069-RTB4-SCREW
RTB
– 5069-RTB4-SPRING
RTB
•SA power (field-side
power)
– 5069-RTB6-SCREW
RTB
– 5069-RTB6-SPRING
RTB
5069-AENTR,
5069-AENTRK
Power (MOD power and SA power on same terminal)
• 5069-RTB5-SCREW RTB
• 5069-RTB5-SPRING RTB
IMPORTANT: You must order RTBs separately. The RTBs are available in
5069 RTB kits.
• The 5069-RTB64-SCREW kit contains the 5069-RTB6-SCREW and 5069-
RTB4-SCREW RTBs.
• The 5069-RTB64-SPRING kit contains the 5069-RTB6-SPRING and 5069-
RTB4-SPRING RTBs.
• The 5069-RTB5-SCREW kit contains the 5069-RTB5-SCREW RTBs.
• The 5069-RTB5-SPRING kit contains the 5069-RTB5-SPRING RTBs.
We recommend that you order only the RTB type that your system requires.
External
power supply
for Module
(MOD) Power
A power supply that is adequately sized to provide MOD power, that is,
system-side power, to the Compact 5000 I/O system.
For more information, see System Power Considerations
on page 8.
External
power supply
for Sensor/
Actuator (SA)
Power
A power supply that is adequately sized to provide SA power, that is, field-
side power, to the Compact 5000 I/O system.
For more information, see System Power Considerations
on page 8.
Tools
You use the following tools to wire the RTBs:
•Screwdriver
• Wire stripper
•Wires
For more information on available wire sizes and wire insulation stripping
length, see Specifications
on page 19.
DIN rail
Compatible zinc-plated, chromate-passivated steel DIN rail.
You can use the following DIN rails:
• EN50022 - 35 x 7.5 mm (1.38 x 0.30 in.)
• EN50022-35 x 15 mm (1.38 x 0.59 in.) - 5069-AENTR and 5069-AENTRK
only
EtherNet/IP
network
components
You must install the network and all required components.
Software
If you do not use the rotary switches to set the adapter IP address, you can use
the following software to set the IP address:
•DHCP server
• BOOTP DHCP EtherNet/IP Commissioning Tool - We recommend that you
use version 3.02.00 or later.
•RSLinx® Classic software
For more information, see Set the Network Internet Protocol (IP) Address
on
page 9.
ATTENTION: Do not discard the end cap. Use this end cap
to cover the exposed interconnections on the last module
on the DIN rail. Failure to do so could result in equipment
damage or injury from electric shock.
IMPORTANT When you mount the DIN rail vertically, the
operating ambient temperature must be derated to
30% of the maximum Ta or 42 °C (108 °F).
