1732E ArmorBlock 2 Port Ethernet Module 11
Publication
1732E-IN004A-EN-E - November 2009
Refer to the illustration for configuration operations.
Configure Operations
Refer to On-Machine Connectivity Catalog, publication M116-CA001, for
Rockwell Automation cable and cord set offerings or use the configuration
tools available at
www.ab.com/e-tools/.
LINK 1 LINK 2
EtherNet/IP D-Code
M12 connector
Network address switches
Module/network
status LED indicators
I/O status LED
indicators
Auxiliary power
44945
Eight M12 I/O
connectors
EtherNet/IP D-Code
M12 connector
