Allen-Bradley CompactLogix 5370 L1 User Manual

Rockwell Automation Publication 1769-UM021G-EN-P - October 2015 117
CompactLogix 5370 Controllers Overview Chapter 5
Controller Functionality
Tab le 3 describes functionality available with CompactLogix 5370 controllers.
Table 3 - CompactLogix 5370 Controller Functionality
Cat. No. Controller Tasks
Supported
Programs
Supported Per
Task
Internal Energy
Storage Solution
EtherNet/IP
Network
Topology
Support
Power Supply
Distance Rating
On-board User
Memory Size
Local I/O Module
Support
1769-L16ER-BB1B
32 1000
Yes - Eliminating
the need for a
battery
Support the
following
topologies:
• Device-level
ring (DLR)
• Linear
• Traditional star
NA
384 KB
As many as six
1734 POINT I/O
modules
(2)
1769-L18ER-BB1B
512 KB
As many as eight
1734 POINT I/O
modules
(2)
1769-L18ERM-BB1B
1769-L19ER-BB1B 1 MB
1769-L24ER-QB1B
See footnote
(1)
768 KB
As many as four
Compact I/O
modules
1769-L24ER-QBFC1B
1769-L27ERM-QBFC1B 1 MB
1769-L30ER
4
1 MB
As many as eight
Compact I/O
modules
1769-L30ER-NSE
1769-L30ERM
1769-L33ER
2 MB
As many as 16
Compact I/O
modules
1769-L33ERM
1769-L36ERM
3 MB
As many as 30
Compact I/O
modules
(1) CompactLogix 5370 L2 controllers have an embedded power supply. Therefore, you do not need to consider power supply distance rating when installing the controller. The Compact I/O modules that
are used as local expansion modules in a CompactLogix 5370 L2 control systems operate on a CompactBus and do have a power supply distance rating you must consider when installing those modules.
For more information on power supply distance rating regarding using Compact I/O modules in a CompactLogix 5370 L2 control system, see page 125
and page 221.
(2) IMPORTANT: You can use up to the maximum number of 1734 POINT I/O modules with the CompactLogix 5370 L1 controllers that are listed in Tab le 1
, as long as the total current drawn by the modules
does not exceed the available POINTBus™ backplane current of 1 A. If you must use more local expansion modules than the POINTBus backplane current supports, you can install a 1734-EP24DC
POINT I/O expansion power supply between local expansion modules to increase the POINTBus backplane power and meet your system requirements.
