8 ControlLogix AC (74-265V) Output Module
Publication 1756-5.16 - September 1999
Wiring example
$IWHUILHOGVLGHZLULQJLVFRPSOHWHVHFXUHWKHZLUHVLQWKHVWUDLQUHOLHIDUHDZLWKDFDEOHWLH
12
34
5
6
7
8
910
11
12
1314
1516
1718
19
20
40178-M
NOTES: All terminals with the same name are connected together on the module.
For example, L1 can be connected to any terminal marked L1-0.
When you daisy chain from a group to another RTB, always connect the daisy
chain to the terminal directly connected to the supply wire, as shown above.
This wiring example shows a single voltage source.
Daisy chain to
other RTBs
Group 0Group 0
Group 1Group 1
L2
1756-OA8
L1-0
L1-0
L1-0
L1-0
L1-1
L1-1
L1-1
L1-1
L1-0
L1-1
OUT-0
OUT-1
OUT-2
OUT-3
OUT-4
OUT-5
OUT-6
OUT-7
Not used
Not used
L1
