ControlLogix DeviceNet Scanner Module 27
Publication 1756-IN566B-EN-P - April 2001
Specifications
Parameter Specification
Module Location any slot in the ControlLogix chassis
Maximum Backplane Current Load 600mA @ 5.0V dc and 3mA @ 24V dc
from ControlLogix chassis backplane
Maximum DeviceNet Current Load 90mA maximum @11-25V dc
30mA typical @ 11-25V dc
Power Dissipation 5.3W maximum
Environmental Conditions
Operational Temperature:
Storage Temperature:
Relative Humidity:
0 to 60°C (32° to 140°F)
-40° to 85°C (-40° to 185°F)
5-95% without condensation
Shock Unpackaged 30g operational
50g non-operational
Vibration Unpackaged 5g from 10-150Hz
Conductors
Category 2
(1)
(1)
Refer to the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
Agency Certification
(when product is marked)
Listed Industrial Control Equipment
Certified Process control Equipment
Certified Class I, Division 2, Group A,B,C,D
Approved class I, Division 2, Group A,B,C,D
Marked for all applicable directives
N223
Marked for all applicable acts
Allen-Bradley
