16 ControlLogix DeviceNet Scanner Module
Publication 1756-IN566B-EN-P - April 2001
Interpreting the Alphanumeric Display
Your 1756-DNB scanner module displays alphanumeric codes that
provide diagnostic information about your module. The
alphanumeric display flashes the codes at approximately 1 second
intervals.
What is Displayed?
As an example, the display for RUN toggles between the network
address and the mode:
A#01
RUN
If there is a problem, the display shows the network address,
followed by the MAC ID of the problem node, followed by the error
code. The display toggles through these elements until the error is
corrected.
A#01
N#33
E#72
The following table summarizes the codes.
Alphanumeric Status Codes
Code Description Recommended Action
70 Scanner failed Duplicate Node
Address check
Change the scanner address to
another available one. The node
address you selected is already in use
on that network.
71 Illegal data in scan list table (node
number alternately flashes).
Reconfigure the scan list table and
remove any illegal data.
72 Slave device stopped communicating
(node number alternately flashes).
Inspect the slave devices and verify
connections.
73 Device’s identity information does not
match electronic key in scan list table
entry (node number alternately
flashes).
Verify that the correct device is at this
node number. Make sure the device at
the scrolling node address matches
the desired electronic key (vendor,
product code, product type, etc.).
