Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 103
Communication Networks Chapter 5
Figure 10 - ControlLogix Universal Remote I/O Communication Example
Universal Remote I/O Network
ControlLogix Controller
PLC-5 Controller in Adapter Mode
1746-ASB and I/O Modules
1771-ASB and I/O Modules
1794-ASB and I/O Modules
