Chapter 11 Using the PhaseManager Tool
Figure 39 - PhaseManager Overview
MainTask
Tas ks
Water Feed
Other code controls the specific actions of your equipment.
My Equipment Program
Mix Phase
MainProgram
Controller Tags
Controller
Add Water Phase
A PHASE tag gives you the status of an equipment phase.
An equipment phase directs one activity of your equipment.
A state model divides the activity into a series of states.
How to add water
Running State Routine
Drain Phase
Space Parts Phase
Conveyor Enable Axes
Equipment phase instructions control the transitions between states and handle faults.
PSC POVR PCLF PRNP PATT
PCMD PFL PXRQ PPD PDET
