Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 55
Start Using the Controller Chapter 3
7. Click Finish.
A confirmation dialog box opens.
8. Click Yes.
The progress dialog box indicates the progress of the firmware upgrade.
The 1756-L7x controllers indicate progress in updates and blocks, where
the 1756-L6x controllers indicate progress only in blocks.
If you are using a 1756-L7x controller and experience a Script File Error after selecting the firmware revision number (see the
example below), there is likely an anomaly with your firmware files.
To recover, take these actions:
• Go to
http://www.rockwellautomation.com/support/ and download the firmware revision you are trying to upgrade. Replace the
firmware revision you have previously installed with that posted on the Technical Support website.
• If replacing your firmware revision does not resolve the anomaly, contact Rockwell Automation Technical Support.
1756-L6x Controller Progress1756-L7x Controller Progress
Allow the firmware update to fully complete before cycling power or otherwise
interrupting the upgrade.
If the ControlFLASH upgrade of the controller is interrupted, the 1756-L6x and
1756-L7x controllers revert to boot firmware, that is firmware revision 1.xxx.
